Pillarhouse Fusion 4
Introduction
The Pillarhouse Fusion 4 is the Pillarhouse’s new generation inline selective soldering platform. It combines low cycle times with the flexibility you are used to, compact machine length and a competitive market price.
To achieve the shortest possible cycle times, up to four sub-process stations can be configured as a fluxer, preheater and two consecutive hot tubs. These can even be of double bath design.
Details
- Various configurations, from 2 to 4 stations
- Adjustable size PCB frame holder
- Lateral framing
- Encoder servomotors on X, Y and Z axes
- 1,5 mm – 25 mm solder nozzle
- Dropjet fluxer
- Top and bottom IR preheater
- Preheating control with an infrared thermometer
- Automatic positioning point control
- Measuring and adjusting the source wave height
- Automatic solder dispensers
- Complete selective soldering lines Nutek conveyor tracks are available with up to palette rebates
Product Options
- Ultrasonic flux application unit
- Top side infra preheating unit
- Closed feedback preheating with pyrometer
- Large solder bath design with multiple chimneys
- Independent Z-axis double-bath design
- Laser panel curvature compensation
- Solder bath rapid exchange trolley
- Automatic solder wire dispenser with built-in recognition
- Dual lane design
- PillarGen Nitrogen Generator
Image gallery
Product showcase videos
Fusion
Multi-sided configurable inline equipment at an economical price.
